"KW?" models include the "Original" Firestik® antennas
|Model: KW3-64A9A-?||Complete 3Ft Dual Antenna Kit||$120.99 (MSRP*)|
|Model: KW4-64A9A-?||Complete 4Ft Dual Antenna Kit||$124.99 (MSRP*)|
"FS?" models include the tunable-tip Firestik® II antennas
|Model: FS3-64A9A-?||Complete 3Ft Dual Antenna Kit||$128.99 (MSRP*)|
|Model: FS4-64A9A-?||Complete 4Ft Dual Antenna Kit||$132.99 (MSRP*)|
Whereas "?" designates antenna color; B=Black; R=Red; W=White; BB=Blue;.
*MSRP (Manufactures Suggested Retail Price) in U.S. Dollars
High performance CB antenna kits complete with 3 or 4 foot antennas, and 3-way mounting brackets that will allow you to mount the antennas on a vertical or horizontal mirror arm or rail as well as directly to any flat vertical surface. The kits also includes our dual-18 foot Fire-Flex cophase harness made from top grade RG-59A/U coaxial cable complete with three screw-on PL-259 connections. And, as a bonus for purchasing a complete kit, we throw in 2 FREE stainless steel springs and a FREE microphone hanger.
Co-phased (or dual) antennas are normally chosen for use by vehicle owners that spend much of their time on the interstate highways. Dual antenna systems create a transmission pattern that has increased field strength directly in front and behind the vehicle. This is especially helpful on vehicles pulling large trailers that tend to shield the antennas radiated energy in one or more directions. Co-phase antenna systems are also useful on vehicles that are lacking in ground plane (composite materials, etc.) as they use the magnetic field from one another as the RF field counterpoise. However, to work properly the antenna mounts MUST have a good chassis ground and the antennas MUST have unobstructed line-of-site between the top 50% or more of the antennas overall length.
There is also much talk regarding the spacing between the antennas. Many people believe that dual antennas will not work unless they are spaced 1/4 wave length (approx 9ft) apart. While this may be true to the nth degree, it does not mean that they will not work with lesser spacing. The spacing will have some effect on the radiation pattern but short of testing every installation and weighing the results against a 9ft spaced installation on the same vehicle, it cannot be assumed that the spacing is better or worse for performance on that particular vehicle. We have seen satisfactory results with antennas spaced as close as 5ft apart. WHERE TO BUY?
And don't forget ... ALL antennas, regardless of style or manufacturer, MUST be tuned after installation on the vehicle. Transmitting antennas are not "plug-n-play" devices. Read our article regarding this matter. Also, visit our technical library to find the answers to your most common questions or to learn how to troubleshoot and tune your CB antenna. It is unique on the Internet!
